10-30A DC Equipment Standard Performance EMI Filter
DBA4
1
Rated Current：10A-30A
General Purpose EMI Filter
Certificate：cUL,CQC,CE,R
Can be customize according to customer requirements.
Support free samples
General Purpose EMI Filter
Certificate：cUL,CQC,CE,R
Can be customize according to customer requirements.
Support free samples
Quantity
Product Details
| Product Name: | DBA4 Low Pass EMI Filter |
| Rated Current: | 10-30A |
| Rated Voltage: | 110VAC-250VAC |
| Working Frequency: | 50/60HZ |
| Temperature Range: | -25℃~85℃ |
| Withstand Test Voltage: | 1750VAC |
| Fire Resistance： | UL 94V-0 |
| Certification： | cUL,CE,CQC,ROHS |
Featured and Benefits
- DBA4 Filters are Designed for Quick and Easy Installation
- Three Connection Methods of Power Cord, Insert and Bolt
- Very Low Leakage Current
- Single Pole Filter Design
- Chokes with High Permeability Core Material and Excellent Thermal Performance
- All EMI Filters Provide Excellent Conduction Attenuation
Application Field
- laser Cutting Equipment
- Industrial Robot Control System
- Electronic Control Equipment
- Small Power Control Equipment
- large Kitchen Equipment
DOREXS provides a wide variety of EMI/EMC filter options, standardized and customized electromagnetic interference solutions.
Provide customers with comprehensive engineering technical support.
